C1206H103J1GACT500

C1206H103J1GACT500, High Temperature Surface Mount C0G MLCC, SMD/SMT, 100volts 10000pF, 5%

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~6.00

PartNumber:: C1206H103J1GACT500

Brand:: Kemet Corporation - KEMET | Pack: SMD | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kani's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-07

From Other Seller

Part Number:C1206H103J1GACT500
US $0.50 - 6.00
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The C1206H103J1GACT500 High Temperature Surface Mount C0G MLCC features a robust and proprietary base metal dielectric system that offers industry-leading performance relative to capacitance and case size combined with capacitance stability at extreme temperatures up to +200ºC. This new platform promotes downsizing opportunities of existing High Temperature C0G technology, and offers replacement opportunities of existing X7R/BX/ BR technologies. Typical applications of C1206H103J1GACT500 include critical timing, tuning, circuits requiring low loss, circuits with pulse, high current, decoupling, by-pass, fi ltering, transient voltage suppression, blocking and energy storage for use in extreme environments commonly present in applications such as down-hole exploration, aerospace engine compartments and geophysical probes.

Parametrics

C1206H103J1GACT500 absolute maximum ratings: (1)Operating Temperature Range: -55℃ to +200℃; (2)Temperature Coefficient of Capacitance : ±30PPM/℃ (up to 200℃); (3)Aging Rate (Max % Cap Loss/Decade Hour): 0%; (4)Dielectric Withstanding Voltage: 250%; (5)Dissipation Factor (DF) @ 25℃: .001 (0.10%) Max; (6)Insulation Resistance (IR) Limit @ 25℃: 1000 megohm microfarads or 100GΩ; (7)Insulation Resistance (IR) Limit @ 200℃: 10 megohm microfarads or 1GΩ.

Features

C1206H103J1GACT500 features: (1)No Piezoelectric Noise; (2)Extremely low ESR and ESL; (3)High Thermal Stability; (4)High Ripple Current Capability; (5)Preferred capacitance solution at line frequencies and into the MHz range; (6)No capacitance change with respect to applied rated DC voltage; (7)Minimal capacitance change with respect to temperature from -55℃ to +200℃; (8)No capacitance decay with time; (9)Non-polar device.
