C1206Y473K1RACTU

C1206Y473K1RACTU, Flexible Termination capacitor, SMD/SMT, 100volts, 47000pF, 10%, X7R

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.00~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.00~0.10

PartNumber:: C1206Y473K1RACTU

Brand:: Kemet Corporation - KEMET | Pack: SMD | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kani's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-07

From Other Seller

Part Number:C1206Y473K1RACTU
US $0.00 - 0.10
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The C1206Y473K1RACTU is a Flexible Termination capacitor (FF-CAP).The C1206Y473K1RACTU exhibits a predictable change in capacitance with respect to time and voltage and boast a minimal change in capacitance with reference to ambient temperature. Capacitance change is limited to ±15% from -55℃ to +125℃. Typical applications of C1206Y473K1RACTU include circuits with a direct battery or power source connection, critical and safety relevant circuits without (integrated) current limitation and any application that is subject to high levels of board flexure or temperature cycling. Examples include raw power input side filtering (power plane/bus), high current applications (automobile battery line) and circuits that cannot be fused to open. Markets include consumer, medical, industrial (power supply), automotive, aerospace and telecom.

Parametrics

C1206Y473K1RACTU absolute maximum ratings: (1)Capacitance: 47000pF; (2)Tolerance: 20%; (3)Voltage Rating: 100volts; (4 Temperature Coefficient/ Code: X7R; (5) Operating Temperature Range: -55℃ to +125℃; (6)Termination Style: SMD/ SMT.

Features

C1206Y473K1RACTU features: (1)-55℃ to +125℃ operating temperature range; (2)Superior flex performance (up to 5mm); (3)Floating Electrode/fail open design; (4)Low to mid capacitance flex mitigation; (5)Pb-Free and RoHS compliant; (6)EIA 0603, 0805, 1206, 1210, and 1812 case sizes; (7)DC voltage ratings of 6.3V, 10V, 16V, 25V, 50V, 100V, 200V and 250V; (8)Capacitance offerings ranging from 180pF to 0.22μF; (9)Available capacitance tolerances of ±5%, ±10% and ±20%; (10)Non-polar device, minimizing installation concerns; (11)100% pure matte tin-plated termination finish allowing for excellent solderability; (12)SnPb termination finish option available upon request (5% min).
