Product Summary
The ES1PD-E3/84A is a Surface Mount Ultrafast Plastic Rectifier. The ES1PD-E3/84A is ideal for use in high frequency rectification and freewheeling application in switching mode converters and inverters for consumer, computer, automotive and telecommunication.
Parametrics
ES1PD-E3/84A absolute maximum ratings: (1)Reverse Voltage: 200 V; (2)Forward Voltage Drop: 0.92 V; (3)Recovery Time: 15 ns; (4)Forward Continuous Current: 1 A; (5)Max Surge Current: 30 A; (6)Reverse Current IR: 5 uA; (7)Operating junction and storage temperature range TJ, TSTG: - 55 to + 150℃.
Features
ES1PD-E3/84A features: (1)Low profile package; (2)Ideal for automated placement; (3)Glass passivated chip junction; (4)Ultrafast recovery times for high efficiency; (5)Low forward voltage, low power losses; (6)High forward surge capability; (7)Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃; (8)Solder dip 260℃, 40 s; (9)Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ES1PD-E3/84A |
Vishay Semiconductors |
Rectifiers 1.0 Amp 200 Volt |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
ES1PA-E3/84A |
Vishay Semiconductors |
Rectifiers 1.0 Amp 50 Volt |
Data Sheet |
|
|
||||||||||||
 |
ES1PA-E3/85A |
Vishay Semiconductors |
Rectifiers 1.0 Amp 50 Volt 30 Amp IFSM |
Data Sheet |
Negotiable |
|
||||||||||||
|
ES1PAHE3/84A |
Vishay Semiconductors |
Rectifiers 1.0 Amp 50 Volt 30 Amp IFSM |
Data Sheet |
Negotiable |
|
||||||||||||
|
ES1PAHE3/85A |
Vishay Semiconductors |
Rectifiers 1.0 Amp 50 Volt 30 Amp IFSM |
Data Sheet |
Negotiable |
|
||||||||||||
|
ES1PA-M3/84A |
|
DIODE ULTRA FAST 1A 50V SMP |
Data Sheet |
|
|
||||||||||||
|
ES1PB-E3/84A |
Vishay Semiconductors |
Rectifiers 1.0 Amp 100 Volt |
Data Sheet |
Negotiable |
|
||||||||||||
